Strobelight Control MIDI Interface



Design and electronics by
Bill Vorn
Montréal (Québec) Canada
© 2004





The Strobelight Control Interface is a 20-output device that converts MIDI messages to 10v pulses. These pulses can be used to trigger strobe lights (non-DMX) or any device accepting low current 10v control signals (trigs or gates). It is based on Pavo's MIDItools interface with relay driver board.


Front view

Back view



Technical Specs



• Dimensions

• AC Power

• Output

• Input

9 (H) x 48 (W) x 36 (D) cm

110 VAC 60 Hz

10 VDC, 20 outputs (XLR3)
